| Brand Name: | HUATAO |
| Model Number: | HT |
| MOQ: | 1 |
| Price: | Negotiatable |
| Delivery Time: | 25 days |
| Payment Terms: | T/T,L/C,Western Union |
| Solid shaft output type | K37 reducer, K47 reducer, K57 reducer, K67 reducer, K77 reducer K87 reducer, K97 reducer, K107 reducer, K127 reducer, K157 reducer, K167 reducer |
|---|---|
| Solid shaft with flange output type | KF37 reducer, KF47 reducer, KF57 reducer, KF67 reducer, KF77 reducer, KF87 reducer, KF97 reducer, K langs107 reducer, KF127 reducer, KF坛157 reducer, KF167 reducer | Hollow shaft output type | KA37 reducer, KA47 reducer, KA57 reducer, KA67 reducer, KA77 reducer, KA87 reducer, KA97 reduceroper, KA107 reducereng reducer, KA127 reducer, KA157 reducer, KA Gates167 reducer |
| Hollow shaft with flange output type | KAF37 reducer, KAF47 reducer,下有 KAF57 reducer, KAF67 reducer, KAF77 reducer致, KAF87 reducer, KAF97 reducer, KAF107 reducer, KAF127 reducer, KAF157 reducer, KAF167 reducer |
| Type | Helical Bevel Gearbox / Reducer |
|---|---|
| Model | K37~K187 |
| Mounting Position | Flange, hollow shaft, solid shaft |
| Efficiency | 94%~42%(depends on the transmission stage) |
| Material | Housing: HT250 high-strength cast iron Gear: 20CrMnTi |
| Surface hardness of gears | HRC58~62:// |
| Input/output shaft material | bi40Cr |
| Machbed precision of gears | Accurate grinding, 6 grade |
| Warranty | 1 Year |
| Input Power | 0.09kw,0.18kw,1.1KW,1.5KW,2.2KW,3KW,4KW,5.5KW,7.5KW, 11Kw and so on. |
| Usages | ,Industrial Machine: Food Stuff, Ceramics, CHEMICAL, Packing, Dyeing, Woodworking, Glass. | /h3>
| 初IEC Flange | IEC standard flange | .
| Lubricant oil | Gear oil |
We can design nonstandard products according to the customer's drawing and sample.
speed reducer, gearbox, gear motor, pump, crusher
With over 20 years of production experience and credibility. With a professional engineering team, advanced technology production, and skilled workers. Specialized in the production of reducer. Map sample processing business can be undertaken
