K Series Gearbox
Created with Pixso. K157 Flange Mounting K Series Gearbox Spiral Bevel Gearboxes For Machinery
name
  • name
  • name
  • name

K157 Flange Mounting K Series Gearbox Spiral Bevel Gearboxes For Machinery

Brand Name: HUATAO
Model Number: HT
MOQ: 1
Price: Negotiatable
Delivery Time: 25 days
Payment Terms: T/T,L/C,Western Union
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
CE, ISO, TUV
Product Name:
K157 Flange Mounting Spiral Bevel Gearboxes For Machinery
Key Words:
K157 Spiral Bevel Gearboxes For Machinery
Application:
Industrial Machinery
Color:
Basis On Customer Request
Customized:
Available
Package:
Plywood Case
HS Code:
8483409000
Production Capacity:
5000PCS/Per Month
Packaging Details:
Plywood Case
Supply Ability:
5000PCS/Per Month
Highlight:

flange mounting k series gearbox

,

k157 k series gearbox

,

k157 spiral bevel gearboxes

Product Description

K157 Flange Mounting Spiral Bevel Gearboxes for Machinery





K157 Flange Mounting Spiral Bevel Gearboxes for Machinery accommodate motor power ranging from 11 kW to 160 kW, making it suitable for various applications.

The K157 Flange Mounting Spiral Bevel Gearboxes for Machinery offers a wide range of gear ratios from 12.65 to 150.41, allowing for precise control over speed and torque



We provide customized support for OEM, ODM, and OBM.



Technical Data Sheet of K157 Flange Mounting Spiral Bevel Gearboxes for Machinery

  • Size: KAF37~KAF187

  • Input Power(kW):0.12~200

  • Technical Data(N·m): 200~50000

  • Gear Ratio: 5.36~179.86 (imax:13461)

Model of K Series High Torque Variator Gearbox Helical Reducer


Solid shaft output type K37 reducer, K47 reducer, K57 reducer, K67 reducer, K77 reducer, K87 reducer, K97 reducer, K107 reducer, K127 reducer, K157 reducer, K167 reducer
Solid shaft with flange output type KF37 reducer, KF47 reducer, KF57 reducer, KF67 reducer, KF77 reducer, KF87 reducer, KF97 reducer, KF107 reducer, KF127 reducer, KF157 reducer, KF167 reducer
Hollow shaft output type KA37 reducer, KA47 reducer, KA57 reducer, KA67 reducer, KA77 reducer, KA87 reducer, KA97 reducer, KA107 reducer, KA127 reducer, KA157 reducer, KA167 reducer
Hollow shaft with flange output type KAF37 reducer, KAF47 reducer, KAF57 reducer, KAF67 reducer, KAF77 reducer, KAF87 reducer, KAF97 reducer, KAF107 reducer, KAF127 reducer, KAF157 reducer, KAF167 reducer




Material of KAF Series Helical Gear Spiral Bevel Gear Motor Reducer

1. Box body: HT250 high-strength cast iron, injection-shaped inner cavity, effectively reduces parts wear；
2. Gear: 20CrMo alloy steel, carbon-nitrogen co-infiltration treatment (maintain tooth surface hardness HRC60 after fine grinding)；
3 . Flat key: 45 steel, surface hardness HRC50.




Type Helical Bevel Gearbox / Reducer
Model K37~K187
Mounting Position Flange, hollow shaft, solid shaft
Efficiency 94%~98%(depends on the transmission stage)
Material Housing: HT250 high-strength cast iron
Gear: 20CrMnTi
Surface hardness of gears HRC58~62
Input/output shaft material 40Cr
Machining precision of gears Accurate grinding, 6 grade
Warranty 1 Year
Input Power
0.09kw,0.18kw,1.1KW,1.5KW,2.2KW,3KW,4KW,5.5KW,7.5KW,
11Kw and so on.
Usages
Industrial Machine: Food Stuff, Ceramics, CHEMICAL, Packing, Dyeing,
Woodworking, Glass.
IEC Flange IEC standard flange
Lubricant oil Gear oil






K157 Flange Mounting K Series Gearbox Spiral Bevel Gearboxes For Machinery 2
Packaging:
K157 Flange Mounting K Series Gearbox Spiral Bevel Gearboxes For Machinery 3
FAQ:

1. Can you customize it according to our requirements?
We can design nonstandard products according to the customer's drawing and sample.
2. What's your product range?
speed reducer, gearbox, gear motor, pump, crusher
3. What is the reason why we buy from you?
With over 20 years of production experience and credibility. With a professional engineering team, advanced technology production, and skilled workers.Specialized in the production of reducer. Map sample processing business can be undertaken
