Delco Paper Calendering  Calender Roller Oil Thermo Flow system

Introduction of  Oil Thermo Caleder Roller Paper :

Thermo canlender roll shell is manufactured of chilled cast iron. The roll has peripherally drilled longitudinal hole to the surface. The heat transferring oil circulates in those holes and then be led out.

The roll journals are made of steel and fastened to the roll shell with bolts The journals have conical mating surface for roller bearings and are furnished with oil channels for bearing dismounting by pressurized oil, the roll surface difference of temperature ≤±2℃

Thermo calender roller technical data sheet:

Thermo calender roller bearing house:

Spherical roller bearing                     2pcs

Bearing type                          23152 -FAG

Bearing house material                       cast steel

Bearing lubrication                         Thin oil lubrication

Thin oil flow requirement                     8L/min

Rotary  joint                              2pcs-Kadant

Thermo calender roller heating system:

--SUPPLIED BY CLIENT

Function        Heat the heating fluid and adjust temperature

Electrical heating unit                    1set

The precision of temperature control       ±1℃

Heating-oil temperatur                    Max.260℃

Rate of heating                       60~260℃   +2℃ /min

About us

Huatao Group was founded in 2008. We are a professional and leading supplier of various rollers for paper, corrugated board, rubber & plastic industry ,nonwoven fabric industries over 15 years of experience.

Paper Industry: forming roller, vacuum couch roller, dandy roller ,Breast Roller, press roller,stone roller, rubber roller,dryer cylinder ,size press roller, calender roller, pope reel roller ,spreader roller ,embossing roller.

Plastic & Rubber: chill roller, MDO Preheating Roller, MDO nip roller, MDO stretching Roller, cooling roller, corona treater roller, Corona treatment nip roller, flame roller, carbon fiber contact roller, carbon fiber tension roller, carbon fiber nip roller, winding core , coating drum, cooling drum, spreader roller, anilox roller,calender roller, embossing roller .

Nonwoven Fabric :cylinder roller, doffer roller ,carbon fiber guide roller , embossing roller, cooling roller ,spreader roller

With a strong commitment to innovation, reliability, and customer satisfaction, Huatao Group has become a trusted provider in the industry and our products have been exported to more than 96 countries and have a good reputation.

Huatao understands that each customer may have different requirements, which cannot meet from one factory, but we can meet, we are also familiar with domestic factory advantages with matching superior quality and help customer not walk bend road. We pursue:each customer is buying and using HUATAO products with a rest assured heart and service is never end.
