| Brand Name: | HUATAO |
| Model Number: | HT |
| MOQ: | 1 |
| Price: | Negotiatable |
| Delivery Time: | 25 days |
| Payment Terms: | T/T,L/C,Western Union |
| Specification | Details |
|---|---|
| Ratio | 3.77-276.77 |
| Input power | 0.12-200KW |
| Output torque | 3.5-21700N.m |
| Output speed | 5-352rpm |
| Mounting type | Foot mounted, foot mounted with solid shaft, output flange mounted, hollow shaft mounted, B5 flange mounted with hollow shaft, foot mounted with hollow shaft, B14 flange mounted with hollow shaft, foot mounted with splined hole, foot mounted with shrink disk, hollow shaft mounted with anti-torque arm. |
| Input Method | Flange input(AM), shaft input(AD), inline AC motor input, or AQA servo motor |
| Brake Release | HF-manual release(lock in the brake release position), HR-manual release(automatic braking position) |
| Thermistor | TF(Thermistor protection PTC thermistor), TH(Thermistor protection Bimetal switch) |
| Mounting Position | M1, M2, M3, M4, M5, M6 |
| Type | FA37-FA157 |
| Output shaft diameter | 25mm, 30mm, 35mm, 40mm, 50mm, 60mm, 70mm, 90mm, 110mm, 120mm |
| Housing material | HT200 high-strength cast iron from R37,47,57,67,77,87 |
| Housing material (higher models) | HT250 High strength cast iron from R97 107,137,147,157,167,187 |
| Heat treatment technology | Carbonitriding and hardening treatment |
| Efficiency | 92%-94% |
| Lubricant | VG220 |
| Protection Class | IP55, F class |
| Output Type | Model Numbers |
|---|---|
| Solid shaft output type | F37, F47, F57, F67, F77, F87, F97, F107, F127, F157 reducer |
| Solid shaft with flange output type | FA37, FA47, FA57, FA67, FA77, FA87, FA97, FA107, FA127, FA157 reducer |
| Hollow shaft output type | FF37, FF47, FF57, FF67, FF77, FF87, FF97, FF107, FF127, FF157 reducer |
| Hollow shaft with flange output type | FAF37, FAF47, FAF57, FAF67, FAF77, FAF87, FAF97, FAF107, FAF127 reducer, FAF157 reducer |
