| Brand Name: | HUATAO |
| Model Number: | HT |
| MOQ: | 1 |
| Price: | Negotiatable |
| Delivery Time: | 25 days |
| Payment Terms: | T/T,L/C,Western Union |
| Parameter | Specification |
|---|---|
| Ratio | 3.77-276.77 |
| Input power | 0.12-200KW |
| Output torque | 3.5-21700N.m |
| Output speed | 5-352rpm |
| Mounting type | Multiple options including foot mounted, flange mounted, hollow shaft mounted, and specialized configurations |
| Input Method | Flange input, shaft input, inline AC motor input, or AQA servo motor |
| Housing material | HT200/HT250 high-strength cast iron |
| Efficiency | 92%-94% |
| Protection Class | IP55, F class |
| Type | Models |
|---|---|
| Solid shaft output type | F37, F47, F57, F67, F77, F87, F97, F107, F127, F157 reducer |
| Solid shaft with flange output type | FA37, FA47, FA57, FA67, FA77, FA87, FA97, FA107, FA127, FA157 reducer |
| Hollow shaft output type | FF37, FF47, FF57, FF67, FF77, FF87, FF97, FF107, FF127, FF157 reducer |
| Hollow shaft with flange output type | FAF37, FAF47, FAF57, FAF67, FAF77, FAF87, FAF97, FAF107, FAF127, FAF157 reducer |
